Billet Rod Honda Gx340/390/420 4.450 X 1.419 .788 Connecting
ARC Racing

Billet Rod Honda GX340/390/420 4.450" X 1.419" X .788"

$149.95
/
Shipping calculated at checkout.

ARC billet +.040" long connecting rod for the Honda GX390. 4.450" center to center for a 1.416" crank pin and a .788" wrist bore. Manufactured from domestic 7075-T651 aluminum and uses 5/16" rod bolts designed and produced by ARP. Also comes with custom made babbit rod bearings. Features ARC's forced oil dipper system. For use with the ARC DJ-3395-F piston. Always check for minimum piston to head clearance of .030"

May require internal clearancing. Includes bearing and ARP rod bolts.

Rod bolt torque: 26 ft/lbs Lubricated
