Dyno Cams Camshaft 315 Grind, Welded Lobe, 196cc, Predator Hemi
The 315 lobe design is the next step above our proven 308. With slightly more lift and increased duration, the 315 will make more top end power for an OHV modified engine. This cam requires an upgraded spring package, billet rod, and billet flywheel.
The Lobes on this Cam are Welded for extra durability.
Engine: 196cc OHV Clone, 212cc Hemi Predator
Recommended Class: Modified
Target (MAX) RPM: 9000
Spring Pressure (In / Ex): 34-36 lbs
Valve Lash (In/Ex): .003"
Ignition Timing: 34 Deg BTDC
Open: 49.80 BTDC 99.65 BBDC
Close: 98.80 ABDC 63.05 ATDC
Lift: .3135" .3135"
C/L: 108.0 ATDC 108.0 BTDC
DUR @ 50: 249.65 Deg 253.40 Deg
