Dyno Cams Camshaft 356 Grind Welded Lobe 196Cc Predator Hemi

Dyno Cams Camshaft 356 Grind, Welded Lobe, 196cc, Predator Hemi

Regular price$107.50
/
Shipping calculated at checkout.

The DynoCams 356 is a high lift modified grind that is very capable of extreme RPMs. This cam has very aggressive ramps and requires an upgraded spring package, billet rod, and billet flywheel. For use with Tillotson or larger carb.
The lobes are welded for extra durability, extending the life of this cam.

Specs
Engine: 196cc OHV Clone, 212cc Hemi Predator
Recommended Class: Modified
Target (MAX) RPM: 8500-9000
Spring Pressure (In / Ex): 36 lbs
Valve Lash (In/Ex): .003"
Ignition Timing: 36 Deg BTDC

Profile
Intake Exhaust
Open: 51.6 BTDC 94.0 BBDC
Close: 93.5 ABDC 54.8 ATDC
Lift: .3555" .3555"
C/L: 108.0 ATDC 108.0 BTDC
DUR @ 50: 254.3 Deg 254.5 Deg
