Dyno Cams Camshaft 335 Grind, Welded Lobe, 196cc, Predator Hemi
The 335 has a big duration with lower lift so it can be used in large cubic inch OHV engines where valve to piston clearances are minimal. This cam requires an upgraded spring package, billet rod, and billet flywheel.
The Lobes on this Cam are Welded.
Engine: 196cc OHV Clone, 212cc Hemi Predator
Recommended Class: Modified
Target (MAX) RPM: 8500-9000
Spring Pressure (In / Ex): 36 lbs
Valve Lash (In/Ex): .003"
Ignition Timing: 36 Deg BTDC
Open: 55.20 BTDC 96.65 BBDC
Close: 95.75 ABDC 60.70 ATDC
Lift: .334" .334"
C/L: 108.0 ATDC 108.0 BTDC
DUR @ 50: 259.75 Deg 264.70 Deg
