Dyno Cams Camshaft CL1 Original Grind, Clone, Hemi
Designed in 2010, this cam was the Original power house for clone engines. The CL1 Original has a wide power band and is a strong cam in restricted clases.
The DynoCams CL-1 Original is legal for the current profile rules for stock classes.
The lobes are hardened for extra durability, extending the life of this cam.
Engine: 196cc OHV Clone, 212cc Hemi Predator
Recommended Class: Restricted
Target (MAX) RPM: 5200-5800
Spring Pressure (In / Ex): 10.8 lbs
Valve Lash (IN/EX): .003"
Ignition Timing: 32 Deg BTDC
Open: 43.0 BTDC 80.5 BBDC
Close: 76.5 ABDC 41.0 ATDC
Lift: .224" .231"
C/L: 108.5 ATDC 110.0 BTDC
DUR @ 50: 219.0 Deg 222.5 Deg
DUR @ 200: 85.5 Deg 98.0 Deg
