Dyno Cams Camshaft CL1 Improved Grind, Clone, Hemi
Designed in 2011, the CL1 Improved has a more retarded centerline to produce optimal top end horsepower.
The DynoCams CL-1 Improved is legal for the current profile rules for stock classes.
The lobes are hardened for extra durability, extending the life of this cam.
Engine: 196cc OHV Clone, 212cc Hemi Predator
Recommended Class: Stock
Target (MAX) RPM: 6000-6500
Spring Pressure (In / Ex): 10.8 lbs
Valve Lash (IN/EX): .003"
Ignition Timing: 32 Deg BTDC
Open: 39.0 BTDC 76.5 BBDC
Close: 82.0 ABDC 47.0 ATDC
Lift: .224" .231"
C/L: 112.5 ATDC 106.0 BTDC
DUR @ 50: 219.0 Deg 222.5 Deg
DUR @ 200: 86.5 Deg 98.0 Deg
