Dyno Cams Camshaft CL4 Grind, NKA Legal, Clone, Hemi, Buffed
The CL4 is specifically designed for the NKA rule package. With no minimum duration requirements, we were able to smooth the nose of the cam allowing it to rev well into the 7000 RPM range. The CL4 shows gains in the 6600 RPM range over our current CL3. This cam comes buffed, further smoothing the nose, to take max advantage of the 10.8 springs.
The CL4 is not legal for AKRA.
The lobes are hardened for extra durability, extending the life of this cam.
Engine: 196cc OHV Clone, 212cc OHV Predator
Recommended Class: NKA Unrestricted Stock Classes
Target (MAX) RPM: 6900-7100
Spring Pressure (In / Ex): 10.8 lbs
Valve Lash (In/Ex): .001"
Ignition Timing: 34-36 Deg BTDC
Open: 28.75 BTDC 66.30 BBDC
Close: 75.25 ABDC 40.52 ATDC
Lift: .224" .231"
C/L: 114.0 ATDC 103.5 BTDC
DUR @ 50: 220.1 Deg 223.5 Deg
DUR @ 200: 79.90 Deg 89.45 Deg
